Helio Board (Discontinued)

Intel^® Cyclone^® V SoC Starter Kit

Thanks for your interesting to this board , but unfortunately this board is discontinued and we are pleased to recommend our new SoC evaluation board [Sodia]. Please visit to Sodia board web site.


Helio is starter kit to evaluate latest Cyclone V SoC ARM-based FPGA. It provides rich features and software compatible with Intel^® SoC FPGA development board. Engineers can evaluate Cyclone V SoC with Helio board in an easy, simple, and cost effective way

Features

Main device:	Cyclone V SoC / 5CSXFC5C6U23C7N with Dual-core ARM* Cortex™-A9 processor
Power device:	LTC2978, LTC3605, LTC3613, LTC3026, LT3509
Memory:	Micron DDR3 1GB @ 32bit @ 400MHz
Configuration:	On board USB Blaster II, Configuration ROM, JTAG
Software:	Yocto Linux BSP support
Interfaces:	HSMC, Gigabit Ethernet, USB 2.0 OTG, UART, SD card, GPIO, LCD
Other Features:	Power Supply Monitor by Linear Technology, Real Time clock, Buttons, LEDs, Switches

Datasheet

http://www.rocketboards.org/foswiki/Documentation/MacnicaHelioSoCEvaluationKit
